Part Number:MS3470S10-6PH
Product Description:
Another remarkable feature of the MIL-DTL-26482 series Ⅱ is its
voltage rating of 500V. This makes it an ideal product for use in
high voltage applications where safety and reliability are of
utmost importance. The product is designed to meet the requirements
of various industries, including military, aerospace, and
industrial applications.
The MIL-DTL-26482 series Ⅱ is made from high-quality materials,
including stainless steel passivated finish, which makes it highly
resistant to corrosion and other forms of damage. The use of
stainless steel passivated finish ensures that the product can
withstand harsh environments and offer reliable performance over an
extended period. The product is also designed to be robust and
sturdy, which makes it an ideal choice for use in heavy-duty
applications.
In summary, the MIL-DTL-26482 series Ⅱ is a high-quality product
that offers reliable performance in extreme environments. Its
ability to operate in temperatures ranging from -55°C to +125°C
makes it ideal for use in harsh environments where other products
may fail. The product's voltage rating of 500V makes it an ideal
choice for use in high voltage applications where safety and
reliability are of utmost importance. The use of stainless steel
passivated finish ensures that the product is highly resistant to
corrosion and other forms of damage, making it an ideal choice for
use in heavy-duty applications.
Features:
- Product Name: MIL-DTL-26482 Series 2
- Shell size: 10
- Connector Type: Circular
- Current Rating: 7.5A
- Finsh: Stainless Steel Passivated
- Contact Finish: Gold
Technical Parameters:
| Product Name | MIL-DTL-26482 Series Ⅱ |
| Connector Type | Circular |
| Gender | Square Flange Receptacle |
| Number of Contacts | 6 |
| Contact Type | Solder |
| Shell Size | 10 |
| Current Rating | 7.5A |
| Voltage Rating | 500V |
| Contact Finish | Gold |
| Operating Temperature | -55°C to +125°C |
| Additional Attributes | Square flange receptacle, Stainless Steel Passivated |
Applications:
The MIL-DTL-26482 Series 2 product is designed to be used in
various applications that require reliable and robust electrical
connections. The product is suitable for use in harsh environments,
making it ideal for military and industrial applications.
The KAIDA MS3470S10-6PH is commonly used in the aerospace industry
for avionics, navigation, and communication systems. The product is
also used in ground-based military equipment such as radar systems,
missile launchers, and communication equipment.
The product is also ideal for use in industrial applications such
as oil and gas drilling, mining, and chemical processing plants.
The KAIDA MS3470S10-6PH can be used in equipment such as motors,
pumps, and sensors that require a reliable electrical connection.
Overall, the KAIDA MS3470S10-6PH MIL-DTL-26482 Series 2 product is
a versatile and reliable square flange receptacle that can be used
in a wide range of applications. Its robust design and gold contact
finish make it suitable for use in harsh environments, ensuring
that electrical connections remain secure and reliable.
Support and Services:
The MIL-DTL-26482 Series 2 product technical support and services
include:
- Product installation assistance
- Product troubleshooting and technical issue resolution
- Product repair and maintenance services
- Product documentation and user manuals
- Product training and education
- Product customization and engineering support
- Product lifecycle management and obsolescence planning
Packing and Shipping:
Product Name: MIL-DTL-26482 Series 2
Product Type: Circular Connector
Product Description: MIL-DTL-26482 Series 2 connectors are designed
for harsh environments and are used in military and aerospace
applications.
Packaging: The MIL-DTL-26482 Series 2 connectors will be packaged
in a durable cardboard box with foam padding to protect the
connectors during shipping.
Shipping: The connectors will be shipped via a reputable carrier
such as FedEx or UPS. The shipping cost will be calculated based on
the weight and destination of the package.
FAQ:
Q: What is the brand name of this product?
A: The brand name of this product is KAIDA.
Q: What is the model number of this product?
A: The model number of this product is MS3470S10-6PH.
Q: Where is this product made?
A: This product is made in China.
Q: Is this product compatible with MIL-DTL-26482 Series 1?
A: No, this product is only compatible with MIL-DTL-26482 Series 2.
Q: What is the maximum operating temperature of this product?
A: The maximum operating temperature of this product is 175°C.
